SECURMATIC R

AUTOMATIC RESCUE DEVICE (A.R.D.) FOR TRACTION LIFTS

– Automatic emergency functioning for mains blackout
– An internal logic circuit chooses the best direction, bringing lift car to floor level and opening doors to leave passengers safely outside
– Suitable for any winch motor lift plant
– Works on both new and old plant
– Minimum maintenance
– Special models on request

Please fill in this formi if you have particular technical requirement not met by our standard products list.
We will examin data and provide an offer for the particular device, if applicable

If you wish you may contact us here

The A.R.D. equipment operates automatically upon mains blackout occurrence. It drives the hoist gear motor by means of a static frequency converter powered by a storage batteries bank, brings the car to the nearest floor and opens automatic doors.

During energency operation a special load sensing circit automaticaly choses the best travel direction in counterweighted lift systems, whenever an unbalance is detected between car load and counterweight.

Current standard production:
– Mains 380-415V – 50 Hz, threephase
– Motor 380-415V– 50 Hz, threephase
– DC Brake (60/110/180V)

Door operator motor

Type A: AC three phase door operator motor, supplied only at floor level (3×127/220/380V)
Type B DC three phase door operator motor, armature and field (60/110/180V), supplied only at floor
